Union Semiconductor International Limited UM4601

UM4601
Part No.:
UM4601
Manufacturer:
Union Semiconductor International Limited
Category:
EMI/RFI Filters (LC, RC Networks)
Package:
8-UFDFN
Description:
4-Line LC EMI Filter with TVS
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Inventory:0

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments

In Stock:0

Qty. Unit Price Ext. Price
RFQ now Add to cart

Product Details

  • Specifications
  • FAQ
  • Comparison
  • Related
Product attributes
Attribute value
Manufacturer:
Union Semiconductor International Limited
Series:
-
Package/Case:
8-UFDFN
Packaging:
Tape & Reel (TR)
Product Status:
Active
Type:
Low Pass
Filter Order:
3rd
Technology:
LC (Pi)
Number of Channels:
4
Center / Cutoff Frequency:
150MHz (Cutoff)
Attenuation Value:
-24dB @ 800MHz, -41dB @ 2 ~ 5GHz
Resistance - Channel (Ohms):
10
Current:
-
Values:
L = 17nH, C = 15pF
ESD Protection:
Yes
Operating Temperature:
-40°C ~ 85°C
Applications:
Data Lines for Mobile Devices
Voltage - Rated:
5V
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Size / Dimension:
0.079" L x 0.079" W (2.00mm x 2.00mm)
Height:
0.031" (0.80mm)
Category:
EMI/RFI Filters (LC, RC Networks)
