NXP USA Inc. MC33696FJAE

MC33696FJAE
Part No.:
MC33696FJAE
Manufacturer:
NXP USA Inc.
Category:
RF Transceiver ICs
Package:
32-VFQFN Exposed Pad
Datasheet:
Leatech Electronics GmbHMC33696FJAE.pdf
Description:
IC RF TXRX ISM<1GHZ 32QFN
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Inventory:990

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments

In Stock:990

Qty. Unit Price Ext. Price
RFQ now Add to cart

Product Details

  • Specifications
  • FAQ
  • Comparison
  • Related
Product attributes
Attribute value
Manufacturer:
NXP USA Inc.
Series:
-
Package/Case:
32-VFQFN Exposed Pad
Packaging:
Bulk
Product Status:
Obsolete
Programmable:
Not Verified
Type:
TxRx Only
RF Family/Standard:
General ISM < 1GHz
Protocol:
-
Modulation:
FSK, OOK
Frequency:
290MHz ~ 340MHz, 424MHz ~ 510MHz, 862MHz ~ 1.02GHz
Data Rate (Max):
22.6kbps
Power - Output:
7.25dBm
Sensitivity:
-106.5dBm
Memory Size:
-
Serial Interfaces:
SPI
GPIO:
-
Voltage - Supply:
2.1V ~ 3.6V
Current - Receiving:
10.3mA ~ 24mA
Current - Transmitting:
6.1mA ~ 13.5mA
Operating Temperature:
-20°C ~ 85°C
Grade:
-
Qualification:
-
Supplier Device Package:
32-QFN-EP (5x5)
Category:
