Rotary Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Number of Positions | Index Stops | Number of Decks | Number of Poles per Deck | Circuit per Deck | Contact Timing | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Length | Angle of Throw | Contact Material | Contact Finish | Mounting Type | Termination Style | Features | Depth Behind Panel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
57M22-12A16NSWITCH ROTARY 16POS 250MA 115V |
0 |
|
Datasheet |
57 | Bulk | Active | 16 | Continuous | 12 | 1 | SP16T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 22.5° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 122.66mm |
|
|
57M22-12B16NSWITCH ROTARY 16POS 250MA 115V |
0 |
|
Datasheet |
57 | Bulk | Active | 16 | Fixed | 12 | 1 | SP16T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 22.5° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 122.66mm |
|
|
24803-10NSWITCH ROTARY 10POS |
0 |
|
Datasheet |
24 | Bulk | Active | 10 | Continuous | - | 1 | SP10T | Non-Shorting (BBM) | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
D9G0723NSWITCH ROTARY 2-23POS 250MA 115V |
0 |
|
Datasheet |
D9 | Bulk | Active | 2 ~ 23 | Adjustable | 7 | 1 | SP23T | Non-Shorting (BBM) | 250mA (AC), 1.5A (DC) | 115 V | 28 V | Round (6.35mm Dia) | 47.63mm | 15° | Brass | Silver | Panel Mount | Solder Lug | - | 89.97mm |
|
|
53M15-12A24NSWITCH ROTARY 24POS 250MA 115V |
0 |
|
Datasheet |
53 | Bulk | Active | 24 | Continuous | 12 | 1 | SP24T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 15° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 122.66mm |
|
|
44M30-12-1-12NSWITCH ROTARY 12POS 1A 115V |
0 |
|
Datasheet |
44 | Bulk | Active | 12 | Continuous | 12 | 1 | SP12T | Non-Shorting (BBM) | 1A (AC/DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 11.10mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 129.06mm |
|
|
312-3T2ESWITCH ROTARY 3POS 30A 300V |
0 |
|
Datasheet |
312 | Bulk | Active | 3 | Fixed | 2 | 1 | SP3T | Non-Shorting (BBM) | 30A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 117.50mm |
|
|
711-8-T3ESWITCH ROTARY 8POS 7A 125V |
0 |
|
Datasheet |
711 | Bulk | Obsolete | 8 | Fixed | 3 | 1 | SP8T | Non-Shorting (BBM) | 7A (AC/DC) | 125 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder, Quick Connect - 0.187" (4.7mm) | - | 62.70mm |
|
|
312-4T2ESWITCH ROTARY 4POS 30A 300V |
0 |
|
Datasheet |
312 | Bulk | Active | 4 | Fixed | 2 | 1 | SP4T | Non-Shorting (BBM) | 30A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 117.50mm |
|
|
59M18-05-1-18NSWITCH ROTARY 18POS 250MA 115V |
0 |
|
Datasheet |
59 | Bulk | Active | 18 | Fixed | 5 | 1 | SP18T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 18° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 57.10mm |
|
|
59M18-05A20NSWITCH ROTARY 20POS 250MA 115V |
0 |
|
Datasheet |
59 | Bulk | Active | 20 | Continuous | 5 | 1 | SP20T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 18° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 57.10mm |
|
|
59M18-05B20NSWITCH ROTARY 20POS 250MA 115V |
0 |
|
Datasheet |
59 | Bulk | Active | 20 | Fixed | 5 | 1 | SP20T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 18° | Silver Alloy | Gold | Panel Mount | Solder Lug | - | 57.10mm |
|
|
412-3T2ESWITCH ROTARY 3POS 50A 300V |
0 |
|
Datasheet |
412 | Bulk | Active | 3 | Fixed | 2 | 1 | SP3T | Non-Shorting (BBM) | 50A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 127.80mm |
|
|
57HS22-12A16NSWITCH ROTARY 16POS 250MA 115V |
0 |
|
Datasheet |
57 | Bulk | Active | 16 | Continuous | 12 | 1 | SP16T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 11.10mm | 22.5° | Silver Alloy | Gold | Panel Mount | Solder Lug | Shaft and Panel Sealed | 122.66mm |
|
|
212-7T2ESWITCH ROTARY 7POS 20A 150V |
0 |
|
Datasheet |
212 | Bulk | Active | 7 | Fixed | 2 | 1 | SP7T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 106.40mm |
|
|
M7G0224NSWITCH ROTARY 2-24POS 125MA 115V |
0 |
|
- |
M7 | Bulk | Active | 2 ~ 24 | Adjustable | 2 | 1 | SP24T | Non-Shorting (BBM) | 125mA (AC), 500mA (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 17.46mm | 15° | Silver Alloy | - | Panel Mount | Solder Lug | - | 42.09mm |
|
212-3T3EMODEL 212 TAP SWITCH 20A 150V |
1 |
|
Datasheet |
212 | Bulk | Active | 3 | Fixed | 3 | 1 | SP3T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 157.20mm |
|
|
E4C0408NSWITCH ROTARY 2-8POS 9A 115V |
0 |
|
Datasheet |
E4 | Bulk | Active | 2 ~ 8 | Adjustable | 2 | 2 | DP8T | Non-Shorting (BBM) | 9A (AC), 11A (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 47.63mm | 20° | Silver (Ag) | - | Panel Mount | Solder Lug | - | 59.64mm |
|
|
312-5T2ESWITCH ROTARY 5POS 30A 300V |
0 |
|
Datasheet |
312 | Bulk | Active | 5 | Fixed | 2 | 1 | SP5T | Non-Shorting (BBM) | 30A (AC/DC) | 300 V | 20 V | Flatted (6.35mm Dia) | 28.58mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 117.50mm |
|
|
212-9T2ESWITCH ROTARY 9POS 20A 150V |
0 |
|
Datasheet |
212 | Bulk | Active | 9 | Fixed | 2 | 1 | SP9T | Non-Shorting (BBM) | 20A (AC/DC) | 150 V | 20 V | Flatted (6.35mm Dia) | 12.70mm | 30° | Silver Alloy | - | Panel Mount | Solder Lug | - | 106.40mm |
