Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1641R-334KFIXED IND 330UH 115MA 6.4 OHM TH |
1,000 |
|
Datasheet |
1641R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 330 µH | ±10% | 115 mA | 65mA | Shielded | 6.4Ohm Max | 55 @ 790kHz | 6.5MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
|
1641R-104KFIXED IND 100UH 164MA 3.12OHM TH |
500 |
|
Datasheet |
1641R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 100 µH | ±10% | 164 mA | 120mA | Shielded | 3.12Ohm Max | 50 @ 2.5MHz | 10MHz | - | -55°C ~ 105°C | 2.5 MHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
|
1641R-474KFIXED IND 470UH 94MA 9.5 OHM TH |
350 |
|
Datasheet |
1641R | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 470 µH | ±10% | 94 mA | 58mA | Shielded | 9.5Ohm Max | 60 @ 790kHz | 5.7MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
|
1641-394KFIXED IND 390UH 107MA 7.4 OHM TH |
299 |
|
Datasheet |
1641 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 390 µH | ±10% | 107 mA | 60mA | Shielded | 7.4Ohm Max | 60 @ 790kHz | 6.2MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
2890R-00KFIXED IND 1.2UH 2.4A 75 MOHM TH |
200 |
|
Datasheet |
2890R | Axial | Tape & Reel (TR) | Active | Molded | Phenolic | 1.2 µH | ±10% | 2.4 A | - | Unshielded | 75mOhm Max | 60 @ 7.9MHz | 170MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Through Hole | - | 0.280" Dia x 0.900" L (7.11mm x 22.86mm) | - |
|
|
GA20-103KLFHIGH CURRENT AXIAL POWER CHOKE |
867 |
|
Datasheet |
GA20 | Axial | Tape & Reel (TR) | Active | Toroidal | Ferrite | 100 µH | ±10% | 1.156 mA | 1.2A | Unshielded | 208mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.260" Dia x 0.630" L (6.60mm x 16.00mm) | - |
|
8532-25LFIXED IND 100UH 1.3A 208MOHM SMD |
885 |
|
Datasheet |
8532 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | 100 µH | ±15% | 1.3 A | 640mA | Unshielded | 208mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.860" L x 0.320" W (21.84mm x 8.12mm) | 0.286" (7.26mm) |
|
2474-04LFIXED IND 1.8UH 5.43A 12 MOHM TH |
140 |
|
Datasheet |
2474 | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 1.8 µH | ±15% | 5.43 A | 4.8A | Unshielded | 12mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | - | 0.240" Dia x 0.740" L (6.10mm x 18.80mm) | - |
|
AFDI002828118R2M06INDUCTOR CHOKE |
500 |
|
Datasheet |
AFDI | Radial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Metal | 8.2 µH | ±20% | 40 A | 32A | Shielded | 2.8mOhm Max | - | - | AEC-Q200 | -50°C ~ 155°C | 100 kHz | - | Through Hole | Radial | 1.102" L x 1.102" W (28.00mm x 28.00mm) | 0.429" (10.90mm) |
|
|
AFDI002828114R7M06INDUCTOR CHOKE |
435 |
|
Datasheet |
AFDI | Radial | Tray | Active | Drum Core, Wirewound | Metal | 4.7 µH | ±20% | 53 A | 52A | Shielded | 1.43mOhm Max | - | - | AEC-Q200 | -50°C ~ 155°C | 100 kHz | - | Through Hole | Radial | 1.102" L x 1.102" W (28.00mm x 28.00mm) | 0.429" (10.90mm) |
|
|
LHDM010300AUGV0EDUST CHOKE COIL |
231 |
|
Datasheet |
DM | Vertical, No Base, 2 PC Pin | Bulk | Active | Toroidal | Sendust | 48 µH | ±20% | 10 A | - | Unshielded | 14mOhm Max | - | - | - | -40°C ~ 120°C | 100 kHz | - | Through Hole | Vertical, No Base, 2 PC Pin | 1.358" Dia x 0.630" W (34.50mm x 16.00mm) | - |
|
|
SPFC-EFD30-250PWR FACTOR COR EFD30 PCB 250W |
627 |
|
Datasheet |
SPFC | Radial, Horizontal, 12 Leads | Tray | Active | Wirewound | - | 150 µH | ±10% | 1.4 A | 6.8A | Shielded | 190mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Through Hole | Radial, Horizontal, 12 Leads | 1.181" L x 1.220" W (30.00mm x 31.00mm) | 0.551" (14.00mm) |
|
|
1641R-682JFIXED IND 6.8UH 285MA 1.02OHM TH |
500 |
|
Datasheet |
1641R | Axial | Tape & Reel (TR) | Active | Molded | Iron | 6.8 µH | ±5% | 285 mA | 285mA | Shielded | 1.02Ohm Max | 50 @ 7.9MHz | 55MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
|
LHDM003251AUGV0EDUST CHOKE COIL |
226 |
|
Datasheet |
DM | Vertical, No Base, 2 PC Pin | Bulk | Active | Toroidal | Sendust | 360 µH | ±20% | 3 A | - | Unshielded | 90mOhm Max | - | - | - | -40°C ~ 120°C | 100 kHz | - | Through Hole | Vertical, No Base, 2 PC Pin | 1.299" Dia x 0.551" W (33.00mm x 14.00mm) | - |
|
|
ERU33M-1R4LFLAT WIRE PTH HIGH CURRENT IND 1 |
116 |
|
Datasheet |
ERU33M | Nonstandard, 2 Lead | Tray | Active | Wirewound | Alloy Powder | 1.4 µH | ±15% | 80 A | 120A | Shielded | 0.46mOhm | - | - | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 1.299" L x 1.142" W (33.00mm x 29.00mm) | 0.453" (11.50mm) |
|
|
SMG5025-221KLFMOLDED NON-MAGNETIC SMT INDUCTOR |
750 |
|
Datasheet |
SMG5025 | Nonstandard | Tape & Reel (TR) | Active | Molded | Non-Magnetic | 2.2 µH | ±10% | 620 mA | - | Unshielded | 950mOhm Max | 33 @ 7.9MHz | 135MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | - | 0.500" L x 0.228" W (12.70mm x 5.80mm) | 0.230" (5.84mm) |
|
B82559A5682A020FIXED IND 6.8UH 2.9 MOHM SMD |
260 |
|
Datasheet |
ERU20 - Flat Wire Inductor | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±10% | - | 19A | Shielded | 2.9mOhm Max | - | - | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.878" L x 0.866" W (22.30mm x 22.00mm) | 0.402" (10.20mm) |
|
|
SMG5025-471KLFMOLDED NON-MAGNETIC SMT INDUCTOR |
800 |
|
Datasheet |
SMG5025 | Nonstandard | Tape & Reel (TR) | Active | Molded | Non-Magnetic | 4.7 µH | ±10% | 375 mA | 375mA | - | 2.6Ohm Max | 33 @ 7.9MHz | 90MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | - | 0.500" L x 0.228" W (12.70mm x 5.80mm) | 0.230" (5.84mm) |
|
|
7443642010120WE-HCF FLAT HIGH CURRENT INDUCTO |
143 |
|
Datasheet |
WE-HCF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Manganese Zinc Ferrite (MnZn) | 1.2 µH | ±20% | 45 A | 47A | Shielded | 0.92mOhm Max | - | 42MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | - | 0.394" (10.00mm) |
|
|
7443642010200WE-HCF FLAT HIGH CURRENT INDUCTO |
123 |
|
Datasheet |
WE-HCF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Manganese Zinc Ferrite (MnZn) | 2 µH | ±20% | 45 A | 30A | Shielded | 0.92mOhm Max | - | 30MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | - | 0.394" (10.00mm) |
