Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRP4020CC-100MIND SMD 10UH 1.8A |
2,069 |
|
Datasheet |
SRP4020CC | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Carbonyl Powder | 10 µH | ±20% | 1.8 A | 2.3A | Shielded | 243mOhm Max | - | 19MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.175" L x 0.160" W (4.45mm x 4.06mm) | 0.079" (2.00mm) |
|
APSC000505304R7TS0INDUCTOR POWER |
2,000 |
|
Datasheet |
APSC | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 4.7 µH | ±30% | - | 1.32A | Shielded | 72mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.185" L x 0.185" W (4.70mm x 4.70mm) | 0.118" (3.00mm) |
|
|
74408063100WE-HEPC SMT SHIELDED TINY POWER |
1,451 |
|
Datasheet |
WE-HEPC | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 10 µH | ±20% | 1.35 A | 2.5A | Shielded | 140mOhm Max | - | 27MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 6030 | 0.232" L x 0.232" W (5.90mm x 5.90mm) | 0.116" (2.94mm) |
|
P1167.154NLFIXED IND 150UH 520MA 610MOHM SM |
2,690 |
|
Datasheet |
P1167NL | Nonstandard | Tray | Active | Wirewound | - | 150 µH | ±20% | 520 mA | 520mA | Shielded | 610mOhm Max | - | 5.6MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.297" L x 0.297" W (7.54mm x 7.54mm) | 0.177" (4.50mm) |
|
|
P1167.272NLFIXED IND 2.7UH 3.5A 16 MOHM SMD |
2,690 |
|
Datasheet |
P1167NL | Nonstandard | Tray | Active | Wirewound | - | 2.7 µH | ±30% | 3.5 A | 3.5A | Shielded | 16mOhm Max | - | 40MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.297" L x 0.297" W (7.54mm x 7.54mm) | 0.177" (4.50mm) |
|
|
P1167.333NLFIXED IND 33UH 1.1A 170 MOHM SMD |
2,690 |
|
Datasheet |
P1167NL | Nonstandard | Tray | Active | Wirewound | - | 33 µH | ±20% | 1.1 A | 1.1A | Shielded | 170mOhm Max | - | 13MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.297" L x 0.297" W (7.54mm x 7.54mm) | 0.177" (4.50mm) |
|
|
P1167.362NLFIXED IND 3.6UH 3.1A 20 MOHM SMD |
2,690 |
|
Datasheet |
P1167NL | Nonstandard | Tray | Active | Wirewound | - | 3.6 µH | ±30% | 3.1 A | 3.1A | Shielded | 20mOhm Max | - | 40MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.297" L x 0.297" W (7.54mm x 7.54mm) | 0.177" (4.50mm) |
|
|
P1167.632NLFIXED IND 6.3UH 2.4A 35 MOHM SMD |
2,690 |
|
Datasheet |
P1167NL | Nonstandard | Tray | Active | Wirewound | - | 6.3 µH | ±20% | 2.4 A | 2.5A | Shielded | 35mOhm Max | - | 36MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.297" L x 0.297" W (7.54mm x 7.54mm) | 0.177" (4.50mm) |
|
BMRF00101040R22MD1INDUCTOR POWER |
2,920 |
|
Datasheet |
BMRX | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 220 nH | ±20% | 35 A | 45A | Shielded | 0.6mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.457" L x 0.398" W (11.60mm x 10.10mm) | 0.157" (4.00mm) |
|
|
ETQ-P4M150KFMINDUCTOR FIXED 15UH SMD |
2,000 |
|
Datasheet |
PCC-M0648M-LE | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Metal Composite | 15 µH | ±20% | 4.6 A | 7.2A | Shielded | 66.77mOhm Max | - | - | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
L08052R7CEWTRFIXED IND 2.7NH 1A 80 MOHM SMD |
2,699 |
|
Datasheet |
Accu-L® | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Thin Film | Non-Magnetic | 2.7 nH | ±0.2nH | 1 A | - | Unshielded | 80mOhm Max | 42 @ 450MHz | 10GHz | - | -55°C ~ 125°C | 450 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.083" L x 0.059" W (2.11mm x 1.50mm) | 0.041" (1.04mm) |
|
|
VCTA20161B-R50MS6IND SMD 0.50UH AUTO GRADE CHOKE |
1,990 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 500 nH | ±20% | 3.8 A | 4A | Unshielded | 30mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B-6R8MS6IND SMD 6.8UH AUTO GRADE CHOKE |
1,986 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 6.8 µH | ±20% | 700 mA | 1A | Unshielded | 670mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B-100MS6IND SMD 10.0UH AUTO GRADE CHOKE |
1,971 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 10 µH | ±20% | 500 mA | 800mA | Unshielded | 850mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B-R15MS6IND SMD 0.15UH AUTO GRADE CHOKE |
1,890 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 150 nH | ±20% | 5.4 A | 6.4A | Unshielded | 14mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B-R10MS6IND SMD 0.10UH AUTO GRADE CHOKE |
1,865 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 100 nH | ±20% | 6.5 A | 9A | Unshielded | 9mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B1R5MS6IND SMD 1.5UH AUTO GRADE CHOKE |
1,850 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 1.5 µH | ±20% | 2.3 A | 2.8A | Unshielded | 80mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B-R68MS6IND SMD 0.68UH AUTO GRADE CHOKE |
1,800 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 680 nH | ±20% | 3.4 A | 3.6A | Unshielded | 40mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B-3R3MS6IND SMD 3.3UH AUTO GRADE CHOKE |
1,730 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 3.3 µH | ±20% | 1.2 A | 1.5A | Unshielded | 250mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
|
|
VCTA20161B-R22MS6IND SMD 0.22UH AUTO GRADE CHOKE |
1,670 |
|
Datasheet |
VCTA20161B | 0806 (2016 Metric) | Tape & Reel (TR) | Active | Molded | Metal | 220 nH | ±20% | 5.2 A | 6.6A | Unshielded | 18mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 1 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.047" (1.20mm) |
