FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PSMN2R2-40YSDXMOSFET N-CH 40V 180A LFPAK56 |
1,408 |
|
Datasheet |
TrenchMOS™ | SC-100, SOT-669 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 180A (Tc) | 10V | 2.2mOhm @ 25A, 10V | 3.6V @ 1mA | 63 nC @ 10 V | ±20V | 5130 pF @ 20 V | - | 166W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | LFPAK56, Power-SO8 |
|
TSM032NH04CR RLG40V, 81A, SINGLE N-CHANNEL POWER |
5,000 |
|
Datasheet |
PerFET™ | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 25A (Ta), 81A (Tc) | 7V, 10V | 3.2mOhm @ 40A, 10V | 3.6V @ 250µA | 45 nC @ 10 V | ±20V | 2896 pF @ 25 V | - | 115W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 8-PDFNU (5x6) |
|
AOD7S60MOSFET N-CH 600V 7A TO252 |
4,907 |
|
Datasheet |
aMOS™ | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 600 V | 7A (Tc) | 10V | 600mOhm @ 3.5A, 10V | 3.9V @ 250µA | 8.2 nC @ 10 V | ±30V | 372 pF @ 100 V | - | 83W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
NP50N04YUK-E1-AYLOW VOLTAGE POWER MOSFET |
4,894 |
|
Datasheet |
- | 8-PowerLDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 50A (Tc) | 10V | 4.8mOhm @ 25A, 10V | 4V @ 250µA | 57 nC @ 10 V | ±20V | 3200 pF @ 25 V | - | 1W (Ta), 97W (Tc) | 175°C | Automotive | AEC-Q101 | Surface Mount | 8-HSON (5x5.4) |
|
|
TSM032NH04LCR RLG40V, 81A, SINGLE N-CHANNEL POWER |
4,220 |
|
Datasheet |
PerFET™ | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 25A (Ta), 81A (Tc) | 4.5V, 10V | 3.2mOhm @ 40A, 10V | 2.2V @ 250µA | 50 nC @ 10 V | ±16V | 3007 pF @ 25 V | - | 115W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 8-PDFNU (5x6) |
|
NP60N06VLK-E1-AYP-TRS2 AUTOMOTIVE MOS |
3,222 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 60A (Tc) | 4.5V, 10V | 7.9mOhm @ 30A, 10V | 2.5V @ 250µA | 56 nC @ 10 V | ±20V | 3600 pF @ 25 V | - | 1.2W (Ta), 105W (Tc) | 175°C | Automotive | AEC-Q101 | Surface Mount | TO-252 (MP-3ZP) |
|
|
BUK9Y13-60ELXSINGLE N-CHANNEL 60 V, 7.9 MOHM |
2,940 |
|
Datasheet |
- | SC-100, SOT-669 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 90A (Tc) | 4.5V, 10V | 7.9mOhm @ 20A, 10V | 2.1V @ 1mA | 81 nC @ 10 V | ±10V | 4520 pF @ 25 V | - | 147W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LFPAK56, Power-SO8 |
|
|
NP60N04VLK-E1-AYP-TRS2 AUTOMOTIVE MOS |
2,498 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 60A (Tc) | 4.5V, 10V | 3.9mOhm @ 30A, 10V | 2.5V @ 250µA | 63 nC @ 10 V | ±20V | 3680 pF @ 25 V | - | 1.2W (Ta), 105W (Tc) | 175°C | Automotive | AEC-Q101 | Surface Mount | TO-252 (MP-3ZP) |
|
SI7456CDP-T1-GE3MOSFET N-CH 100V 27.5A PPAK SO-8 |
2,482 |
|
Datasheet |
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 27.5A (Tc) | 4.5V, 10V | 23.5mOhm @ 10A, 10V | 2.8V @ 250µA | 23 nC @ 10 V | ±20V | 730 pF @ 50 V | - | 5W (Ta), 35.7W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® SO-8 |
|
NVMFS5C450NLAFT1GMOSFET N-CH 40V 110A 5DFN |
1,500 |
|
Datasheet |
- | 8-PowerTDFN, 5 Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 110A (Tc) | 4.5V, 10V | 2.8mOhm @ 40A, 10V | 2V @ 250µA | 35 nC @ 10 V | ±20V | 2100 pF @ 20 V | - | 68W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 5-DFN (5x6) (8-SOFL) |
|
IRF9610PBF-BE3MOSFET P-CH 200V 1.8A TO220AB |
996 |
|
Datasheet |
- | TO-220-3 | Tube | Active | P-Channel | MOSFET (Metal Oxide) | 200 V | 1.8A (Tc) | - | 3Ohm @ 900mA, 10V | 4V @ 250µA | 11 nC @ 10 V | ±20V | 170 pF @ 25 V | - | 20W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220AB |
|
R6003KND3TL1MOSFET N-CH 600V 3A TO252 |
102 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 3A (Tc) | 10V | 1.5Ohm @ 1A, 10V | 5.5V @ 1mA | 8 nC @ 10 V | ±20V | 185 pF @ 25 V | - | 44W (Tc) | 150°C (TJ) | - | - | Surface Mount | TO-252 |
|
|
MCU110N06YB-TPN-CHANNEL MOSFET,DPAK |
7,281 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 110A (Tc) | 6V, 10V | 5mOhm @ 55A, 10V | 4V @ 250µA | 80 nC @ 10 V | ±20V | 4150 pF @ 30 V | - | 80W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252 (DPAK) |
|
IRFR024TRLPBFMOSFET N-CH 60V 14A DPAK |
5,000 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 14A (Tc) | 10V | 100mOhm @ 8.4A, 10V | 4V @ 250µA | 25 nC @ 10 V | ±20V | 640 pF @ 25 V | - | 2.5W (Ta), 42W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DPAK |
|
|
MSJPF11N65A-BPN-CHANNEL MOSFET,TO-220F |
4,827 |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 11A | 10V | 380mOhm @ 3.2A, 10V | 4V @ 250µA | 21 nC @ 10 V | ±30V | 763 pF @ 25 V | - | 31.3W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220F |
|
FCD5N60TM-WSMOSFET N-CH 600V 4.6A DPAK |
2,950 |
|
Datasheet |
SuperFET™ | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 4.6A (Tc) | 10V | 950mOhm @ 2.3A, 10V | 5V @ 250µA | 16 nC @ 10 V | ±30V | 600 pF @ 25 V | - | 54W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252AA |
.JPG)
|
TSM048NB06LCR RLGMOSFET N-CH 60V 16A/107A 8PDFN |
7,118 |
|
Datasheet |
- | 8-PowerLDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 16A (Ta), 107A (Tc) | 4.5V, 10V | 4.8mOhm @ 16A, 10V | 2.5V @ 250µA | 105 nC @ 10 V | ±20V | 6253 pF @ 30 V | - | 3.1W (Ta), 136W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 8-PDFN (5.2x5.75) |
|
|
PSMN1R6-25YLEXPSMN1R6-25YLE/SOT669/LFPAK |
1,490 |
|
Datasheet |
- | SC-100, SOT-669 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 185A (Tc) | 7V, 10V | 1.88mOhm @ 25A, 10V | 2.2V @ 1mA | 61 nC @ 10 V | ±20V | 3698 pF @ 12 V | - | 124W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | LFPAK56, Power-SO8 |
|
|
PSMN2R1-30YLEXPSMN2R1-30YLE/SOT669/LFPAK |
1,390 |
|
Datasheet |
- | SC-100, SOT-669 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 160A (Tc) | 7V, 10V | 2.17mOhm @ 25A, 10V | 2.2V @ 1mA | 64 nC @ 10 V | ±20V | 3749 pF @ 15 V | - | 124W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | LFPAK56, Power-SO8 |
|
IPB80N04S403ATMA1MOSFET N-CH 40V 80A TO263-3-2 |
906 |
|
Datasheet |
OptiMOS™ | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 80A (Tc) | 10V | 3.3mOhm @ 80A, 10V | 4V @ 53µA | 66 nC @ 10 V | ±20V | 5260 pF @ 25 V | - | 94W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PG-TO263-3-2 |
