Texas Instruments CSD87334Q3D

CSD87334Q3D
Part No.:
CSD87334Q3D
Manufacturer:
Texas Instruments
Category:
FET, MOSFET Arrays
Package:
8-PowerTDFN
Datasheet:
Leatech Electronics GmbHCSD87334Q3D.pdf
Description:
MOSFET 2N-CH 30V 20A 8VSON
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Inventory:0

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments

In Stock:0

Qty. Unit Price Ext. Price
RFQ now Add to cart

Product Details

  • Specifications
  • FAQ
  • Comparison
  • Related
Product attributes
Attribute value
Manufacturer:
Texas Instruments
Series:
NexFET™
Package/Case:
8-PowerTDFN
Packaging:
Tape & Reel (TR)
Product Status:
Active
Technology:
MOSFET (Metal Oxide)
Configuration:
2 N-Channel (Dual) Asymmetrical
FET Feature:
Logic Level Gate
Drain to Source Voltage (Vdss):
30V
Current - Continuous Drain (Id) @ 25°C:
20A
Rds On (Max) @ Id, Vgs:
6mOhm @ 12A, 8V
Vgs(th) (Max) @ Id:
1.2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:
8.3nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds:
1260pF @ 15V
Power - Max:
6W
Operating Temperature:
-55°C ~ 150°C (TJ)
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Supplier Device Package:
8-VSON (3.3x3.3)
Category:
FET, MOSFET Arrays
