KEMET EA2-4.5TNJ

EA2-4.5TNJ
Part No.:
EA2-4.5TNJ
Manufacturer:
KEMET
Category:
Signal Relays, Up to 2 Amps
Package:
Datasheet:
Leatech Electronics GmbHEA2-4.5TNJ.pdf
Description:
RELAY GEN PURPOSE DPDT 1A 4.5V
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Inventory:0

Please send an inquiry. Send us your inquiry, and we will respond immediately.

Part Number
Quantity
Price
Name
Company
Email
Comments

In Stock:0

Qty. Unit Price Ext. Price
RFQ now Add to cart

Product Details

  • Specifications
  • FAQ
  • Comparison
  • Related
Product attributes
Attribute value
Manufacturer:
KEMET
Series:
EA2
Packaging:
Tube
Product Status:
Active
Mounting Type:
Through Hole
Coil Voltage:
4.5VDC
Contact Form:
DPDT (2 Form C)
Contact Rating (Current):
1 A
Switching Voltage:
250VAC, 220VDC - Max
Load - Max Switching:
250VA, 220W
Coil Current:
70 mA
Coil Type:
Latching, Dual Coil
Features:
-
Termination Style:
PC Pin
Seal Rating:
-
Coil Insulation:
-
Must Operate Voltage:
3.38 VDC
Must Release Voltage:
-
Operate Time:
2 ms
Release Time:
1 ms
Operating Temperature:
-40°C ~ 85°C
Contact Material:
Silver Alloy, Gold Alloy
Relay Type:
General Purpose
Grade:
-
Qualification:
-
Category:
Signal Relays, Up to 2 Amps
