TLE9471ESV33XUMA1

Key Features

• Very low quiescent current consumption in Stop- and Sleep Mode

• Periodic Cyclic Wake in SBC Normal-, Stop- and Sleep Mode

• Periodic Cyclic Sense in SBC Normal-, Stop- and Sleep Mode

• Low-Drop Buck DC/DC Voltage Regulator 3.3 V, 500 mA for main supply with integrated spread spectrummodulation feature for optimum EMC performance

• Low-Drop Linear Voltage Regulator 5 V, 100 mA, protection feature for off-board usage

• High-Speed CAN transceiver supporting FD communication up to 5 Mbit/s according to ISO 11898-2:2016& SAE J2284

• Fully compliant to "Hardware Requirements for LIN, CAN and FlexRay Interfaces in AutomotiveApplications" Revision 1.3, 2012-05-04

• Charge pump-output for N-channel MOSFET reverse-polarity protection or load switch feature withintegrated spread spectrum modulation feature for optimum EMC performance

• Universal High-Voltage Wake input for voltage level monitoring and wake-up detection

• General Purpose High-Voltage in- and output (GPIO) configurable as Fail Output, Wake Input, Low-Sideswitch or High-Side switch

• High-Voltage Measurement function as alternative pin assignment

• Fail Output for Fail-Safe signalization

• Configurable wake-up sources

• Reset & Interrupt outputs

• Configurable timeout and window watchdog

• Overtemperature and short circuit protection feature

• Dedicated TEST pin for SBC Development Mode entry (watchdog counter stopped)

• Software compatible to other SBC families TLE926x and TLE927x

• Wide input voltage and temperature range

• Optimized for Electromagnetic Compatibility (EMC) and low Electromagnetic Emission (EME)

• Optimized for high immunity against Electromagnetic Interference (EMI)

• AEC Qualified & Green Product (RoHS compliant)
