MAX77958EWV+T

The MAX77958 is a robust solution for USB Type-C CCdetection and power delivery (PD) protocol implementation. It detects connected accessories or devices by using Type-C CC detection and USB PD messaging. TheIC protects against overvoltage and overcurrent, and detects moisture and prevents corrosion on the USB TypeC connector. The IC also has a D+/D- USB switch andBC1.2 detection to support legacy USB standards. It contains VCONN switches for USB PD and an enable pin foran external VCONN boost or buck converter. When theUSB PD negotiation is complete, the IC configures an alternate mode setting for external multiplexers.The IC is compliant with USB Type-C Specification Release 1.3 and PD 3.0. It can be customized easily withoutaffecting the compliance.The IC has an I2C master that can read and write to otherdevices in the system so that its firmware can configure related devices without the main processor's assistance. Forexample, it can configure an external charger based onBC1.2 detection, CC detection, and PD communication.The IC has an interrupt output pin to report event detectionand status changes. It also has an I2C interface that thesystem can use to read/write and configure internal registers.The IC has nine configurable GPIOs that can be used fordetection, as interrupts, and as the enable/disable pin forexternal devices, or as ADC inputs.The IC is available in a 3.10mm x 2.65mm, 0.5mm pitch,wafer-level package (WLP).The IC is a highly customizable Power Delivery controllersolution. Contact Analog Devices to check how theMAX77958 can be used for customer-specific use cases
