Leatech Electronics GmbH - Stepper Motors - Motors, Actuators, Solenoids and Drivers - page 19 - Original source of goods

Mfr. Part #	Availability	Price	Quantity	Datasheet	Series	Packaging	Product Status	Type	Coil Type	Voltage - Rated	Current Rating (Amps)	Steps per Revolution	Step Angle	Accuracy	Torque - Holding (oz-in / mNm)	Size / Dimension	NEMA Frame Size	Diameter - Shaft	Length - Shaft and Bearing	Mounting Hole Spacing	Termination Style	Operating Temperature	Coil Resistance	Features
A4K-M564W STEPPER MOTOR 5PHASE 60MM 1.4A Autonics	3	-	RFQ	-	AK	Box	Active	-	Unipolar	24VDC	1.4 A	500.0	0.72°	-	59.48 / 420	Square - 2.362" x 2.362" (60.00mm x 60.00mm)	-	0.315" (8.00mm)	0.945" (24.00mm)	1.969" (50.00mm)	Wire Leads	-10°C ~ 50°C	0.8 Ohms	Double Flatted Shaft
SS2422-50XE100 STPR MTR BIPOLAR 5.4V 1A/PHASE Sanyo	10	-	RFQ	Datasheet	SS	Bulk	Active	Hybrid	Bipolar	5.4VDC	1 A	200.0	1.8°	±0.09%	26.33 / 186	Square - 1.654" x 1.654" (42.00mm x 42.00mm)	-	0.197" (5.00mm)	0.276" (7.00mm)	1.220" (31.00mm)	Wire Leads	-10°C ~ 50°C	5.4 Ohms	-
A2K-S544W-S STEPPER MOTOR 5PHASE 42MM 0.75A Autonics	10	-	RFQ	-	AK	Box	Active	-	Unipolar	24VDC	750 mA	500.0	0.72°	-	25.49 / 180	Square - 1.654" x 1.654" (42.00mm x 42.00mm)	-	0.197" (5.00mm)	0.787" (20.00mm)	1.220" (31.00mm)	Wire Leads	-10°C ~ 50°C	2.2 Ohms	Double Flatted Shaft
A16K-M569W STEPPER MOTOR 5PHASE 60MM 1.4A Autonics	3	-	RFQ	-	AK	Box	Active	-	Unipolar	24VDC	1.4 A	500.0	0.72°	-	235.1 / 1660	Square - 2.362" x 2.362" (60.00mm x 60.00mm)	-	0.315" (8.00mm)	0.945" (24.00mm)	1.969" (50.00mm)	Wire Leads	-10°C ~ 50°C	1.8 Ohms	Double Flatted Shaft
AH4K-S564W STEPPER MOTOR 5PHASE 60MM 0.75A Autonics	5	-	RFQ	-	AHK	Box	Active	-	Unipolar	24VDC	750 mA	500.0	0.72°	-	59.48 / 420	Square - 2.362" x 2.362" (60.00mm x 60.00mm)	-	-	-	1.969" (50.00mm)	Wire Leads	-10°C ~ 50°C	2.6 Ohms	Hollow Shaft
A10K-S545-G5 STEPPER MOTOR 5PHASE 42MM 0.75A Autonics	2	-	RFQ	-	AK-G	Box	Active	-	Unipolar	24VDC	750 mA	2500.0	0.144°	-	141.64 / 1000	Square - 1.654" x 1.654" (42.00mm x 42.00mm)	-	0.315" (8.00mm)	1.102" (28.00mm)	1.220" (31.00mm)	Wire Leads	-10°C ~ 50°C	2.2 Ohms	Round Shaft
AH16K-M569 STEPPER MOTOR 5PHASE 60MM 1.4A Autonics	2	-	RFQ	-	AHK	Box	Active	-	Unipolar	24VDC	1.4 A	500.0	0.72°	-	235.1 / 1660	Square - 2.362" x 2.362" (60.00mm x 60.00mm)	-	-	-	1.969" (50.00mm)	Wire Leads	-10°C ~ 50°C	1.8 Ohms	Hollow Shaft
AH16K-G569 STEPPER MOTOR 5PHASE 60MM 2.8A Autonics	2	-	RFQ	-	AHK	Box	Active	-	Unipolar	24VDC	2.8 A	500.0	0.72°	-	235.1 / 1660	Square - 2.362" x 2.362" (60.00mm x 60.00mm)	-	-	-	1.969" (50.00mm)	Wire Leads	-10°C ~ 50°C	0.56 Ohms	Hollow Shaft
5718X-15P-HP05 NEMA 23 - 1 STACK STEPPER + 5:1 Lin Engineering	10	-	RFQ	Datasheet	5718	Box	Active	Hybrid	Bipolar	24VDC	-	2000.0	-	-	501 / 3,535	Square - 2.25" x 2.25" (57.20mm x 57.20mm)	23	0.63" (16mm)	1.16" (29.5mm)	1.949" (49.50mm)	Wire Leads	-20°C ~ 50°C	300 mOhms	Shaft Key Included
5718M-02P-HP05 NEMA 23 - 2 STACK STEPPER + 5:1 Lin Engineering	10	-	RFQ	Datasheet	5718	Box	Active	Hybrid	Bipolar	24VDC	-	2000.0	-	-	866 / 6,114	Square - 2.25" x 2.25" (57.20mm x 57.20mm)	23	0.63" (16mm)	1.16" (29.5mm)	1.949" (49.50mm)	Wire Leads	-20°C ~ 50°C	500 mOhms	Shaft Key Included
5718M-02P-HP10 NEMA 23 - 2 STACK STEPPER + 10:1 Lin Engineering	10	-	RFQ	Datasheet	5718	Box	Active	Hybrid	Bipolar	24VDC	-	4000.0	-	-	1,730 / 12,211	Square - 2.25" x 2.25" (57.20mm x 57.20mm)	23	0.63" (16mm)	1.16" (29.5mm)	1.949" (49.50mm)	Wire Leads	-20°C ~ 50°C	500 mOhms	Shaft Key Included
5718L-01P-HP05 NEMA 23 - 3 STACK STEPPER + 5:1 Lin Engineering	10	-	RFQ	Datasheet	5718	Box	Active	Hybrid	Bipolar	24VDC	-	2000.0	-	-	1,470 / 10,400	Square - 2.25" x 2.25" (57.20mm x 57.20mm)	23	0.63" (16mm)	1.16" (29.5mm)	1.949" (49.50mm)	Wire Leads	-20°C ~ 50°C	1.1 Ohms	Shaft Key Included
A21K-G596 STEPPER MOTOR 5PHASE 85MM 2.8A Autonics	5	-	RFQ	-	AK	Box	Active	-	Unipolar	24VDC	2.8 A	500.0	0.72°	-	297.4 / 2100	Square - 3.347" x 3.347" (85.00mm x 85.00mm)	-	0.551" (14.00mm)	1.457" (37.00mm)	2.756" (70.00mm)	Wire Leads	-10°C ~ 50°C	0.4 Ohms	Flatted Shaft
A21K-M596 STEPPER MOTOR 5PHASE 85MM 1.4A Autonics	3	-	RFQ	-	AK	Box	Active	-	Unipolar	24VDC	1.4 A	500.0	0.72°	-	297.4 / 2100	Square - 3.347" x 3.347" (85.00mm x 85.00mm)	-	0.551" (14.00mm)	1.457" (37.00mm)	2.756" (70.00mm)	Wire Leads	-10°C ~ 50°C	1.76 Ohms	Flatted Shaft
5718X-15P-HP50 NEMA 23 - 1 STACK STEPPER + 50:1 Lin Engineering	10	-	RFQ	Datasheet	5718	Box	Active	Hybrid	Bipolar	24VDC	-	20000.0	-	-	5,000 / 35,300	Square - 2.25" x 2.25" (57.20mm x 57.20mm)	23	0.63" (16mm)	1.16" (29.5mm)	1.949" (49.50mm)	Wire Leads	-20°C ~ 50°C	300 mOhms	Shaft Key Included
5718X-15P-HP20 NEMA 23 - 1 STACK STEPPER + 20:1 Lin Engineering	10	-	RFQ	Datasheet	5718	Box	Active	Hybrid	Bipolar	24VDC	-	8000.0	-	-	2,000 / 14,120	Square - 2.25" x 2.25" (57.20mm x 57.20mm)	23	0.63" (16mm)	1.16" (29.5mm)	1.949" (49.50mm)	Wire Leads	-20°C ~ 50°C	300 mOhms	Shaft Key Included
5718M-02P-HP20 NEMA 23 - 2 STACK STEPPER + 20:1 Lin Engineering	10	-	RFQ	Datasheet	5718	Box	Active	Hybrid	Bipolar	24VDC	-	8000.0	-	-	3,459 / 24,420	Square - 2.25" x 2.25" (57.20mm x 57.20mm)	23	0.63" (16mm)	1.16" (29.5mm)	1.949" (49.50mm)	Wire Leads	-20°C ~ 50°C	500 mOhms	Shaft Key Included
A41K-M599W STEPPER MOTOR 5PHASE 85MM 1.4A Autonics	4	-	RFQ	-	AK	Box	Active	-	Unipolar	24VDC	1.4 A	500.0	0.72°	-	580.6 / 4100	Square - 3.347" x 3.347" (85.00mm x 85.00mm)	-	0.551" (14.00mm)	1.457" (37.00mm)	2.756" (70.00mm)	Wire Leads	-10°C ~ 50°C	2.6 Ohms	Double Flatted Shaft
A41K-G599W STEPPER MOTOR 5PHASE 85MM 2.8A Autonics	2	-	RFQ	-	AK	Box	Active	-	Unipolar	24VDC	2.8 A	500.0	0.72°	-	580.6 / 4100	Square - 3.347" x 3.347" (85.00mm x 85.00mm)	-	0.551" (14.00mm)	1.457" (37.00mm)	2.756" (70.00mm)	Wire Leads	-10°C ~ 50°C	0.58 Ohms	Double Flatted Shaft
A35K-M566-R5 STEPPER MOTOR 5PHASE 60MM 1.4A Autonics	2	-	RFQ	-	AK-R	Box	Active	-	Unipolar	24VDC	1.4 A	2500.0	0.144°	-	495.6 / 3500	Square - 2.362" x 2.362" (60.00mm x 60.00mm)	-	1.693" (43.00mm)	-	-	Wire Leads	-10°C ~ 50°C	1.1 Ohms	Rotary Actuator

Total 840 Record«Prev 1... 15 16 17 181920 21 22...42 Next»
