Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRP1245CC-220MIND SMD 22UH 7.5A |
356 |
|
Datasheet |
SRP1245CC | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Carbonyl Powder | 22 µH | ±20% | 7.5 A | 11A | Shielded | 58mOhm Max | - | 6MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
|
VCHA075D-1R5MS6IND SMD 1.5UH AUTO GRADE CHOKE |
250 |
|
Datasheet |
VCHA075D | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | 1.5 µH | ±20% | 10.3 A | 14A | Unshielded | 7.3mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 100 kHz | - | Surface Mount | - | 0.303" L x 0.283" W (7.70mm x 7.20mm) | 0.213" (5.40mm) |
|
|
ASPI-F4030-1R0M-TFIXED IND 1UH 10.3A 7.2 MOHM |
2,000 |
|
Datasheet |
ASPI-F4030 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 1 µH | ±20% | 13 A | 10.3A | Shielded | 7.2mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 4030 | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.122" (3.10mm) |
|
|
ASPI-F4030-1R5M-TFIXED IND 1.5UH 8.8A 10.5 MOHM |
2,000 |
|
Datasheet |
ASPI-F4030 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 1.5 µH | ±20% | 10.2 A | 8.8A | Shielded | 10.5mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 4030 | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.122" (3.10mm) |
|
|
ASPI-F4030-4R7M-TFIXED IND 4.7UH 4.4A 31.5 MOHM |
2,000 |
|
Datasheet |
ASPI-F4030 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 4.7 µH | ±20% | 6.6 A | 4.4A | Shielded | 31.5mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 4030 | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.122" (3.10mm) |
|
|
ASPI-F4030-6R8M-TFIXED IND 6.8UH 3.7A 47.9 MOHM |
2,000 |
|
Datasheet |
ASPI-F4030 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 6.8 µH | ±20% | 4.7 A | 3.7A | Shielded | 47.9mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 4030 | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.122" (3.10mm) |
|
|
ASPI-F4030-2R2M-TFIXED IND 2.2UH 7A 15 MOHM |
2,000 |
|
Datasheet |
ASPI-F4030 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 2.2 µH | ±20% | 8.7 A | 7A | Shielded | 15mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | 4030 | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.122" (3.10mm) |
|
MPI4015V2-R22-RFIXED IND 220NH 11A 7.5 MOHM SMD |
1,464 |
|
Datasheet |
MPI40-V2 | Nonstandard, 2 Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Metal Composite | 220 nH | ±20% | 11 A | 14A | Shielded | 7.5mOhm Max | - | 153MHz | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.173" L x 0.165" W (4.40mm x 4.20mm) | 0.059" (1.50mm) |
|
S1210-472KFIXED IND 4.7UH 402MA 1 OHM SMD |
500 |
|
Datasheet |
S1210 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Ferrite | 4.7 µH | ±10% | 402 mA | - | Shielded | 1Ohm Max | 40 @ 7.9MHz | 40MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
|
S1210-104KFIXED IND 100UH 127MA 10 OHM SMD |
500 |
|
Datasheet |
S1210 | 1210 (3225 Metric) | Tape & Reel (TR) | Active | - | Ferrite | 100 µH | ±10% | 127 mA | - | Shielded | 10Ohm Max | 40 @ 2.5MHz | 8MHz | - | -55°C ~ 125°C | 2.5 MHz | - | Surface Mount | 1210 | 0.128" L x 0.095" W (3.25mm x 2.42mm) | 0.101" (2.57mm) |
|
PA5001.101NLTFIXED IND 100NH 18A 2.42MOHM SMD |
4,899 |
|
Datasheet |
PA5001.XXXNLT | Nonstandard | Tape & Reel (TR) | Active | Molded | Ferrite | 100 nH | ±20% | 18 A | 38A | Shielded | 2.42mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.083" (2.10mm) |
|
5800-5R6-RCFIXED IND 5.6UH 2.5A 23 MOHM TH |
864 |
|
Datasheet |
5800 | Axial | Tray | Active | Drum Core, Wirewound | Ferrite | 5.6 µH | ±10% | 2.5 A | 5A | Unshielded | 23mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - | 0.275" Dia x 0.700" L (6.99mm x 17.78mm) | - |
|
|
5800-6R8-RCFIXED IND 6.8UH 2.4A 26 MOHM TH |
849 |
|
Datasheet |
5800 | Axial | Tray | Active | Drum Core, Wirewound | Ferrite | 6.8 µH | ±10% | 2.4 A | 4.4A | Unshielded | 26mOhm Max | - | - | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | - | 0.275" Dia x 0.700" L (6.99mm x 17.78mm) | - |
|
|
78438357033WE-MAIA SMD POWER INDUCTOR |
624 |
|
Datasheet |
WE-MAIA | Nonstandard | Tape & Reel (TR) | Active | - | Iron Alloy | 3.3 µH | ±20% | 5 A | 5A | Shielded | 33.5mOhm Max | - | 26MHz | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.122" (3.10mm) |
|
|
VCHW053T-50NMS5IND SMD 0.05UH AUTO GRADE CHOKE |
1,950 |
|
Datasheet |
VCHW053T | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | 50 nH | ±20% | 40 A | 55A | Unshielded | 0.66mOhm | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.215" L x 0.207" W (5.45mm x 5.25mm) | 0.118" (3.00mm) |
|
ASPI-F7050-2R2M-TIND 2.2UH 14A 6.4M |
1,535 |
|
Datasheet |
ASPI-F7050 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 2.2 µH | ±20% | 17 A | 14A | Shielded | 6.4mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.331" L x 0.315" W (8.40mm x 8.00mm) | 0.201" (5.10mm) |
|
|
74457008WE-PD4 SMT POWER INDUCTOR 0.8 UH |
500 |
|
Datasheet |
WE-PD4 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ferrite | 800 nH | ±20% | 16 A | 35A | Unshielded | 3mOhm Max | - | 92MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
74457127WE-PD4 SMT POWER INDUCTOR 27 UH; |
497 |
|
Datasheet |
WE-PD4 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Metal Composite | 27 µH | ±15% | 3.8 A | 6A | Shielded | 52mOhm Max | - | 12.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
74457139WE-PD4 SMT POWER INDUCTOR 39 UH; |
492 |
|
Datasheet |
WE-PD4 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Ferrite | 39 µH | ±10% | 3.2 A | 5.2A | Unshielded | 78mOhm Max | - | 10.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
VCHA085D-220MS6IND SMD 22.0UH AUTO GRADE CHOKE |
470 |
|
Datasheet |
VCHA085D | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | 22 µH | ±20% | 3.7 A | 6.2A | Unshielded | 67mOhm Max | - | - | AEC-Q200 | -55°C ~ 165°C | 100 kHz | - | Surface Mount | - | 0.343" L x 0.323" W (8.70mm x 8.20mm) | 0.213" (5.40mm) |
