FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MCH5805-TL-EPCH+SBD 4V DRIVE SERIES |
36,000 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
VN2222LLRLSMALL SIGNAL N-CHANNEL MOSFET |
30,204 |
|
Datasheet |
- | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 150mA | 10V | 7.5Ohm @ 500mA, 10V | 2.5V @ 1mA | - | ±20V | 60 pF @ 25 V | - | 400mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-92 (TO-226) |
|
2SK2552B-T1-ATN-CHANNEL SMALL SIGNAL MOSFET |
30,000 |
|
Datasheet |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
NTHS5443T1HPFET CHPFT 20V 4.9A 65MOH |
27,000 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
NTHD4P02FT1MOSFET/SCHOTTKY P-CH 20V CHIPFET |
20,955 |
|
- |
- | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
PMN20EN,115MOSFET N-CH 30V 6.7A 6TSOP |
0 |
|
- |
- | SC-74, SOT-457 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 6.7A (Tj) | 4.5V, 10V | 20mOhm @ 6.7A, 10V | 2.5V @ 250µA | 18.6 nC @ 10 V | ±20V | 630 pF @ 15 V | - | 545mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-74 |
|
|
MCH5819-TL-ENCH+SBD 4V DRIVE SERIES |
18,000 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
NTD23N03RGMOSFET N-CH 25V 3.8A/17.1A DPAK |
0 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 25 V | 3.8A (Ta), 17.1A (Tc) | 4V, 5V | 45mOhm @ 6A, 10V | 2V @ 250µA | 3.76 nC @ 4.5 V | ±20V | 225 pF @ 20 V | - | 1.14W (Ta), 22.3W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DPAK |
|
|
GSFAT0600MOSFET, N-CH, SINGLE, 0.30A, 60V |
15,059 |
|
Datasheet |
- | SOT-523 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 300mA (Ta) | 4.5V, 10V | 3Ohm @ 500mA, 10V | 2.5V @ 250µA | 0.44 nC @ 4.5 V | ±20V | 50 pF @ 25 V | - | 150mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-523 |
|
MCH5837-TL-EMOSFET N-CH 20V 2A 5MCPH |
15,000 |
|
- |
- | 6-SMD (5 Leads), Flat Leads | Bulk | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 2A (Ta) | - | 145mOhm @ 1A, 4V | - | 1.8 nC @ 4 V | - | 115 pF @ 10 V | Schottky Diode (Isolated) | 800mW (Ta) | 150°C (TJ) | - | - | Surface Mount | 5-MCPH |
|
MCH3312-EBM-TL-EPCH 4V DRIVE SERIES |
15,000 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
CPH3422-TL-EMOSFET N-CH |
15,000 |
|
Datasheet |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
SCH1436-TL-WMOSFET N-CH 30V 1.8A SOT563/SCH6 |
0 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 1.8A (Ta) | 4V, 10V | 180mOhm @ 900mA, 10V | 2.6V @ 1mA | 2 nC @ 10 V | ±20V | 88 pF @ 10 V | - | 800mW (Ta) | 150°C (TJ) | - | - | Surface Mount | SOT-563/SCH6 |
|
|
SCH1332-TL-WMOSFET P-CH 20V 2.5A SOT563/SCH6 |
0 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Obsolete | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.5A (Ta) | 1.8V, 4.5V | 95mOhm @ 1.5A, 4.5V | 1.3V @ 1mA | 4.6 nC @ 4.5 V | ±10V | 375 pF @ 10 V | - | 1W (Ta) | 150°C (TJ) | - | - | Surface Mount | SOT-563/SCH6 |
|
|
MCH3412-EBM-TL-ENCH 4V DRIVE SERIES |
12,000 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
CPH5819-TL-ENCH+SBD 4V DRIVE SERIES |
9,000 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
NTD4806NA-1GMOSFET N-CH 30V 11.3A/79A IPAK |
0 |
|
- |
- | TO-251-3 Short Leads, IPAK, TO-251AA | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 11.3A (Ta), 79A (Tc) | - | 6mOhm @ 30A, 10V | 2.5V @ 250µA | 23 nC @ 4.5 V | - | 2142 pF @ 12 V | - | - | - | - | - | Through Hole | IPAK |
|
|
NTD50N03R-1GMOSFET N-CH 25V 7.8A/45A IPAK |
0 |
|
Datasheet |
- | TO-251-3 Short Leads, IPAK, TO-251AA | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 25 V | 7.8A (Ta), 45A (Tc) | 4.5V, 11.5V | 12mOhm @ 30A, 11.5V | 2V @ 250µA | 15 nC @ 11.5 V | ±20V | 750 pF @ 12 V | - | 1.5W (Ta), 50W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | IPAK |
|
SSP1N60AN-CHANNEL POWER MOSFET |
5,115 |
|
Datasheet |
- | TO-220-3 | Bulk | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 1A (Tc) | 10V | 12Ohm @ 500mA, 10V | 4V @ 250µA | 11 nC @ 10 V | ±30V | 190 pF @ 25 V | - | 34W (Tc) | -55°C ~ 150°C (TJ) | - | - | Through Hole | TO-220 |
|
NTD4808N-35GMOSFET N-CH 30V 10A/63A IPAK |
0 |
|
Datasheet |
- | TO-251-3 Stub Leads, IPAK | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Ta), 63A (Tc) | 4.5V, 11.5V | 8mOhm @ 30A, 10V | 2.5V @ 250µA | 13 nC @ 4.5 V | ±20V | 1538 pF @ 12 V | - | 1.4W (Ta), 54.6W (Tc) | -55°C ~ 175°C (TJ) | - | - | Through Hole | IPAK |
