FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NVMFS6H848NT1GMOSFET N-CH 80V 13A/57A 5DFN |
1,500 |
|
Datasheet |
- | 8-PowerTDFN, 5 Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 13A (Ta), 57A (Tc) | 10V | 9.4mOhm @ 10A, 10V | 4V @ 70µA | 16 nC @ 10 V | ±20V | 1180 pF @ 40 V | - | 3.7W (Ta), 73W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 5-DFN (5x6) (8-SOFL) |
|
XP4N2R1MTFET N-CH 40V 37.5A 170A PMPAK |
995 |
|
Datasheet |
XP4N2R1 | 8-PowerLDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 37.5A (Ta), 170A (Tc) | 10V | 2.1mOhm @ 20A, 10V | 5V @ 250µA | 154 nC @ 10 V | ±20V | 9056 pF @ 20 V | - | 5W (Ta), 104W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | PMPAK® 5 x 6 |
|
SQJA46EP-T1_GE3MOSFET N-CH 40V 60A PPAK SO-8 |
14,458 |
|
Datasheet |
TrenchFET® | PowerPAK® SO-8 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 60A (Tc) | 10V | 3mOhm @ 10A, 10V | 3.5V @ 250µA | 105 nC @ 10 V | ±20V | 5000 pF @ 25 V | - | 68W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | PowerPAK® SO-8 |
|
BSC019N04LSTATMA1MOSFET N-CH 40V |
5,000 |
|
Datasheet |
- | - | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 28A (Ta), 161A (Tc) | 4.5V, 10V | 1.9mOhm @ 50A, 10V | 2V @ 250µA | 57 nC @ 10 V | ±20V | 4060 pF @ 20 V | - | 94W (Tc) | -55°C ~ 175°C (TA) | - | - | - | - |
|
|
TQM056NH04CR RLG40V, 54A, SINGLE N-CHANNEL POWER |
5,000 |
|
Datasheet |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 17A (Ta), 54A (Tc) | 7V, 10V | 5.6mOhm @ 27A, 10V | 3.6V @ 250µA | 41 nC @ 10 V | ±20V | 2912 pF @ 25 V | - | 78.9W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount, Wettable Flank | 8-PDFNU (4.9x5.75) |
|
|
TQM056NH04LCR RLG40V, 54A, SINGLE N-CHANNEL POWER |
4,970 |
|
Datasheet |
PerFET™ | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 17A (Ta), 54A (Tc) | 4.5V, 10V | 5.6mOhm @ 27A, 10V | 2.2V @ 250µA | 45.6 nC @ 10 V | ±16V | - | - | 78.9W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 8-PDFN (5x6) |
|
|
PJD70P03E-AU_L2_006A130V P-CHANNEL ENHANCEMENT MODE M |
2,952 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 15A (Ta), 77A (Tc) | 4.5V, 10V | 8.4mOhm @ 20A, 10V | 2.5V @ 250µA | 54 nC @ 10 V | ±25V | 2309 pF @ 25 V | - | 3W (Ta), 79W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TO-252AA |
|
NVTFS6H850NLWFTAGMOSFET N-CH 80V 11A/68A 8WDFN |
1,495 |
|
Datasheet |
- | 8-PowerWDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 11A (Ta), 68A (Tc) | 10V | 9.5mOhm @ 10A, 10V | 4V @ 70µA | 19 nC @ 10 V | ±20V | 1140 pF @ 40 V | - | 3.2W (Ta), 107W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 8-WDFN (3.3x3.3) |
|
DMTH15H017SPS-13MOSFET BVDSS: 101V~250V POWERDI5 |
909 |
|
Datasheet |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 11A (Ta), 61A (Tc) | 8V, 10V | 19mOhm @ 20A, 10V | 4V @ 250µA | 34 nC @ 10 V | ±20V | 2344 pF @ 75 V | - | 1.5W (Ta), 107W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | PowerDI5060-8 |
|
|
NVMFS6H836NWFT3GT8 80V SO8FL |
10,000 |
|
Datasheet |
- | 8-PowerTDFN, 5 Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 15A (Ta), 74A (Tc) | 10V | 6.7mOhm @ 15A, 10V | 4V @ 95µA | 25 nC @ 10 V | ±20V | 1640 pF @ 40 V | - | 3.7W (Ta), 89W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount, Wettable Flank | 5-DFNW (4.9x5.9) (8-SOFL-WF) |
|
|
MCU6D5N06YLQ-TPN-CHANNEL MOSFET,DPAK |
5,000 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 80A (Tc) | 4.5V, 10V | 6.5mOhm @ 20A, 10V | 2.3V @ 250µA | 27 nC @ 10 V | ±20V | 1746 pF @ 30 V | - | 88W (Tj) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DPAK |
|
|
RD3L04BBKHRBTLNCH 60V 40A, TO-252 (DPAK), POWE |
2,789 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 40A (Tc) | 4.5V, 10V | 13.5mOhm @ 40A, 10V | 2.5V @ 348µA | 13 nC @ 10 V | ±20V | 760 pF @ 30 V | - | 53W (Tc) | 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TO-252 |
|
IRFR014PBF-BE3MOSFET N-CH 60V 7.7A DPAK |
1,724 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 7.7A (Tc) | - | 200mOhm @ 4.6A, 10V | 4V @ 250µA | 11 nC @ 10 V | ±20V | 300 pF @ 25 V | - | 2.5W (Ta), 25W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TO-252AA |
|
|
NVMFS6H836NWFT1GMOSFET N-CH 80V 15A/74A 5DFN |
1,500 |
|
Datasheet |
- | 8-PowerTDFN, 5 Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 15A (Ta), 74A (Tc) | 10V | 6.7mOhm @ 15A, 10V | 4V @ 95µA | 25 nC @ 10 V | ±20V | 1640 pF @ 40 V | - | 3.7W (Ta), 89W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount, Wettable Flank | 5-DFNW (4.9x5.9) (8-SOFL-WF) |
|
NVMYS4D1N06CLTWGMOSFET N-CH 60V 22A/100A LFPAK4 |
518 |
|
Datasheet |
- | SOT-1023, 4-LFPAK | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 22A (Ta), 100A (Tc) | 4.5V, 10V | 4mOhm @ 50A, 10V | 2V @ 80µA | 34 nC @ 10 V | ±20V | 2200 pF @ 25 V | - | 3.7W (Ta), 79W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LFPAK4 (5x6) |
|
|
NVMFWS020N06CT1GMOSFET N-CH 60V 9A/28A 5DFN |
0 |
|
Datasheet |
- | 8-PowerTDFN, 5 Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 9A (Ta), 28A (Tc) | 10V | 19.6mOhm @ 4A, 10V | 4V @ 20µA | 5.8 nC @ 10 V | ±20V | 355 pF @ 30 V | - | 3.4W (Ta), 31W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 5-DFN (5x6) (8-SOFL) |
.JPG)
|
TSM033NB04LCR RLGMOSFET N-CH 40V 21A/121A 8PDFN |
4,354 |
|
Datasheet |
- | 8-PowerLDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 21A (Ta), 121A (Tc) | 4.5V, 10V | 3.3mOhm @ 21A, 10V | 2.5V @ 250µA | 79 nC @ 10 V | ±20V | 4456 pF @ 20 V | - | 3.1W (Ta), 107W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 8-PDFN (5.2x5.75) |
|
STP4N52K3MOSFET N-CH 525V 2.5A TO220 |
2,148 |
|
Datasheet |
SuperMESH3™ | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 525 V | 2.5A (Tc) | 10V | 2.6Ohm @ 1.25A, 10V | 4.5V @ 50µA | 11 nC @ 10 V | ±30V | 334 pF @ 100 V | - | 45W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220 |
|
ZXMN3A02X8TAMOSFET N-CH 30V 5.3A 8MSOP |
730 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 5.3A (Ta) | 4.5V, 10V | 25mOhm @ 12A, 10V | 1V @ 250µA | 26.8 nC @ 10 V | ±20V | 1400 pF @ 25 V | - | 1.1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-MSOP |
|
SISH112DN-T1-GE3MOSFET N-CH 30V 11.3A PPAK |
5,612 |
|
Datasheet |
TrenchFET® | PowerPAK® 1212-8SH | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 11.3A (Tc) | 4.5V, 10V | 7.5mOhm @ 17.8A, 10V | 1.5V @ 250µA | 27 nC @ 4.5 V | ±12V | 2610 pF @ 15 V | - | 1.5W (Tc) | -50°C ~ 150°C (TJ) | - | - | Surface Mount | PowerPAK® 1212-8SH |
