FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XP60PN72RENMOSFET N-CH 600V 53MA SOT23 |
2,365 |
|
Datasheet |
XP60PN72 | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 53mA (Ta) | 10V | 72Ohm @ 50mA, 10V | 5V @ 250µA | 4 nC @ 10 V | ±20V | 80 pF @ 100 V | - | 500mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23 |
|
|
DMP3050LVTQ-7MOSFET BVDSS: 25V~30V TSOT26 T&R |
2,278 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Bulk | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 4.5A (Ta) | 4.5V, 10V | 50mOhm @ 4.5A, 10V | 2V @ 250µA | 10.5 nC @ 10 V | ±25V | 620 pF @ 15 V | - | 1.6W (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSOT-26 |
|
NTNS3166NZT5GMOSFET N-CH 20V 0.361A SOT883 |
8,000 |
|
Datasheet |
- | 3-XFDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 361mA (Ta) | 1.5V, 4.5V | 700mOhm @ 200mA, 4.5V | 1V @ 250µA | 0.8 nC @ 4.5 V | ±8V | 24 pF @ 10 V | - | 155mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-883 (XDFN3) (1x0.6) |
|
DMN25D0UFA-7BMOSFET N-CH 25V 240MA 3DFN |
6,980 |
|
Datasheet |
- | 3-XFDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 240mA (Ta) | 2.7V, 4.5V | 4Ohm @ 400mA, 4.5V | 1.2V @ 250µA | 0.36 nC @ 4.5 V | 8V | 27.9 pF @ 10 V | - | 280mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | X2-DFN0806-3 |
|
PMN25ENEXMOSFET N-CH 30V 6.1A 6TSOP |
3,000 |
|
Datasheet |
- | SC-74, SOT-457 | Tape & Reel (TR) | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 30 V | 6.1A (Ta) | 4.5V, 10V | 24mOhm @ 6.1A, 10V | 2.5V @ 250µA | 18 nC @ 10 V | ±20V | 597 pF @ 15 V | - | 560mW (Ta), 6.25mW (Tc) | 150°C (TJ) | - | - | Surface Mount | 6-TSOP |
|
MMFTP2319MOSFET SOT23 -40V -4.2A 0.08OHM |
2,990 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | P-Channel | - | - | 4.2A | - | - | - | - | - | - | - | 750mW | - | - | - | Surface Mount | SOT-23-3 (TO-236) |
|
DMG7408SFG-7MOSFET N-CH 30V 7A POWERDI3333-8 |
2,000 |
|
Datasheet |
- | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 7A (Ta) | 4.5V, 10V | 23mOhm @ 10A, 10V | 2.4V @ 250µA | 17 nC @ 10 V | ±20V | 478.9 pF @ 15 V | - | 1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | POWERDI3333-8 |
|
SSM6K405TU,LFMOSFET N-CH 20V 2A UF6 |
2,480 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 2A (Ta) | 1.5V, 4V | 126mOhm @ 1A, 4V | 1V @ 1mA | 3.4 nC @ 4 V | ±10V | 195 pF @ 10 V | - | 500mW (Ta) | 150°C | - | - | Surface Mount | UF6 |
|
|
DMN3024SFG-7MOSFET N-CH 30V 7.5A PWRDI3333-8 |
844 |
|
Datasheet |
- | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 7.5A (Ta) | 4.5V, 10V | 23mOhm @ 10A, 10V | 2.4V @ 250µA | 10.5 nC @ 10 V | ±25V | 479 pF @ 15 V | - | 900mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | POWERDI3333-8 |
|
PJA3415AE_R1_00001SOT-23, MOSFET |
38,335 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 4.3A (Ta) | 1.8V, 4.5V | 50mOhm @ 4.3A, 4.5V | 1V @ 250µA | 24 nC @ 4.5 V | ±8V | 907 pF @ 10 V | - | 1.25W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23 |
|
DMP21D6UFB4-7BMOSFET P-CH 20V 580MA 3DFN |
9,986 |
|
Datasheet |
- | 3-XFDFN | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 580mA (Ta) | 1.8V, 4.5V | 1Ohm @ 100mA, 4.5V | 1V @ 250µA | 0.8 nC @ 8 V | ±8V | 46.1 pF @ 10 V | - | 510mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | X2-DFN1006-3 |
|
BSH205G2VLMOSFET P-CH 20V 2.3A TO236AB |
4,965 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.3A (Ta) | 1.5V, 4.5V | 170mOhm @ 2A, 4.5V | 950mV @ 250µA | 6.5 nC @ 4.5 V | ±8V | 418 pF @ 10 V | - | 480mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TO-236AB |
|
|
DI025N06PT-AQMOSFET POWERQFN 3X3 65V 0.02OHM |
3,606 |
|
Datasheet |
- | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 65 V | 25A (Tc) | 4.5V, 10V | 20mOhm @ 8A, 10V | 2.5V @ 250µA | - | ±20V | 406 pF @ 30 V | - | 25W (Tc) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | 8-QFN (3x3) |
|
|
PMPB50XNXPMPB50XN/SOT1220-2/DFN2020M-6 |
2,766 |
|
Datasheet |
- | 6-UDFN Exposed Pad | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 110 V | 5A (Ta) | 2.5V, 4.5V | 70mOhm @ 3.9A, 4.5V | 1.4V @ 250µA | 6.7 nC @ 4.5 V | ±12V | 741.5 pF @ 50 V | - | 580mW (Ta), 13W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DFN2020M-6 |
|
DMP2045UFY4-7MOSFET P-CH 20V 4.7A X2-DFN2015 |
2,217 |
|
Datasheet |
- | 3-XDFN | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 4.7A (Ta) | 1.5V, 4.5V | 45mOhm @ 4A, 4.5V | 1V @ 250µA | 6.8 nC @ 4.5 V | ±8V | 634 pF @ 10 V | - | 670mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | X2-DFN2015-3 |
|
PJW8N03_R2_0000130V N-CHANNEL ENHANCEMENT MODE M |
1,482 |
|
Datasheet |
- | TO-261-4, TO-261AA | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 5A (Ta), 7.2A (Tc) | 4.5V, 10V | 38mOhm @ 5.6A, 10V | 2.1V @ 250µA | 7.8 nC @ 10 V | ±20V | 343 pF @ 15 V | - | 1.5W (Ta), 3W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-223 |
|
DMG3407SSN-7MOSFET P-CH 30V 4A SC59 |
2,594 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 4A (Ta) | 4.5V, 10V | 50mOhm @ 4.1A, 10V | 2.1V @ 250µA | 16 nC @ 10 V | ±20V | 700 pF @ 15 V | - | 1.1W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-59-3 |
|
SI1078X-T1-GE3MOSFET N-CH 30V 1.02A SOT563F |
4,687 |
|
Datasheet |
TrenchFET® | SOT-563, SOT-666 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 1.02A (Tc) | 2.5V, 10V | 142mOhm @ 1A, 10V | 1.5V @ 250µA | 3 nC @ 4.5 V | ±12V | 110 pF @ 15 V | - | 240mW (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | - |
|
MMFTP3401-AQMOSFET SOT-23 P -30V -4A 0.05? 1 |
2,875 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 4A (Ta) | 2.5V, 10V | 65mOhm @ 4A, 10V | 1.3V @ 250µA | - | ±12V | 954 pF @ 0 V | - | 1.4W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-3 (TO-236) |
|
DMN2300UFD-7MOSFET N-CH 20V 1.21A 3DFN |
2,708 |
|
Datasheet |
- | 3-UDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 1.21A (Ta) | 1.5V, 4.5V | 200mOhm @ 900mA, 4.5V | 950mV @ 250µA | 2 nC @ 4.5 V | ±8V | 67.62 pF @ 25 V | - | 470mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | X1-DFN1212-3 |
